2002 FORD F-250
Owner/Builder
Specs
ENGINE:
- 1997 forged rod 7.3L Power Stroke with Swamps Diesel Stage 2 beehive valve springs
- Smith Brothers chromoly pushrods
- ARP head studs
FUEL/OIL:
- Performance Injection Systems 300/400 hybrid injectors
- Diesel Innovations regulated return with Fuelab regulator
- Irate Diesel Performance basic competition fuel system
- Beans Diesel Performance sump
- Swamp’s Diesel Gen3 high-pressure oil pump over stock 17-degree pump
TURBO/AIR:
- Engineered Diesel S475-based
- 2.5-inch turbo with billet 63.5mm compressor wheel
- 87mm turbine wheel
- 1.10 A/R exhaust housing
- Irate Diesel Performance T4 turbo mount
- ’99 Super Duty intercooler
EXHAUST:
- Irate Diesel Performance 4-inch downpipe
- MBRP 4-inch system to 6-inch miter-cut bed stack
TUNING:
- Power Hungry Performance custom files via Hydra Chip
TRANSMISSION:
- 4R100 built by Stone’s Performance with DPC 4-disc converter, billet input shaft
- Alto Red clutches, modified pump and valve body
- Matt Maier shift box
HORSEPOWER:
- 600 rwhp (est.)
TORQUE:
- 1,100 lb-ft (est.)
TIRES:
- BFGoodrich All-Terrain T/A, 305/70R16
WHEELS:
- Hoss XD795, 16×8 (front);
- Factory Alcoa, 16×7 (rear)
AXLES:
- Rear Dana 80 with Lincoln locker and 4.63 ring and pinion, front Dana 60 with spool and 4.56 ring and pinion
SUSPENSION:
- Farmboy Fabrications traction bars, blocked rear suspension
