John Mata Jr. November 29, 2023 C10 Builders Guide
Richard Hopkins of Burlington, North Carolina, used to have a pretty cool vintage Chevy pickup back when he was younger. Although the truck is now gone, he still has the greatest memories spent working on it with his father, Richard Sr. (Big Rich). Although that particular truck wasn’t exactly his dream ride, it was still a great project to have and it gave him a great excuse to spend some quality time with his dad.
“That old truck of mine was a ’66 Chevy C10 longbed”, Richard says. “I always wanted a big window shortbed, but I enjoyed what I had back then. Now that I’m older, I was set on finding the exact truck that I wanted so that my son and I could share some of the same experiences I did with my father.”
It didn’t take long for Richard to find the truck he had been coveting for decades. With the keys in his hand for a ’66 C10 with that big back window/shortbed combo, he began work on what would be an absolute showstopper when the Hopkins men were finished with it. Oh yeah, Big Rich hadn’t given up building trucks just yet, and he was ready to help his son as he set out to dig in on yet another classic Chevy pickup.
“…I was set on finding the exact truck that I wanted then so that my son and I could share some of the same experiences I did with my father.”
Before Big Rich got to work, however, Junior kicked off the project by installing Porterbuilt drop member units to the front and rear to get the ’66 sitting down low. Richard then properly upgraded the drop member systems by bolting on Firestone air bags and Ridetech HQ shocks, dual Viair compressors, and an Accuair e-Level air management to quickly and accurately dial in the desired ride height for cruising.
The completed frame was thoroughly powdercoated once all the components had been test fitted to keep everything uniform and well protected from the elements. Richard also treated his truck to Unisteer power rack-and-pinion steering and went so far as to remove the OEM fuel tank to clean and reseal it before mounting it right back in the factory location.
“…Junior kicked off the project by installing Porterbuilt drop member units to the front and rear to get the ’66 sitting down low.”
The factory front braking components were removed and slated to hit the junk pile. They would be replaced with fresh, modular disc brake kits from CPP. The rear drum brakes were serviced, however, as the drums would remain intact for the time being. A Wilwood tandem master cylinder with proportioning valve was added to the mix, as were anodized black caliper covers for an unassuming appearance. Since Richard was looking to staying true to his truck’s timeless ’60s styling, he selected a set of 22×9 Centerline Smoothie wheels that have been finished off with chrome retro hubcaps and performance Falken tires.
With a solid rolling chassis now intact, Richard then moved on to removing the C10’s engine and dropping in something much more special. Big Rich had a ’57 Chevy that he has planned on building soon, as well as a ’57 Chevy 283 V-8 to go along with it that he was interested in breaking in.
“The Chevy C60 air cleaner had to be sectioned, chopped, and rotated 180-degrees in order to clear the underside of the hood.”
Well, the truck was in need of something to power it, so that’s where that classic GM mill is currently residing—a perfect solution for the scenario. This engine wasn’t whipped by just any means though. The father/son duo had souped it up properly, and it now features some very cool performance additions that also make a lasting visual impression underneath the truck’s hood.
Given the C10’s current low-as-hell ride height, a few things had to be done in order for a few things to fit better. The Chevy C60 air cleaner had to be sectioned, chopped and rotated 180-degrees to clear the underside of the hood. The transmission crossmember had to be altered for the Deeds Engineering modular exhaust system to be fed through the frame and not underneath it. After a few more tweaks and additions to the engine, the guys were soon ready to mount a 1969 TH350 transmission, along with an Inland Empire 2-piece driveshaft while still utilizing the factory ’66 Chevy 12-bolt rearend.
“Aside from the routine metal work to get the truck ready for paint, Richard utilized the availability of SelfMade Fab’s shaved and bead-rolled firewall panels and front and rear wheel tubs.”
A lot of hard work had been sunk into the project at this point, but Richard was nowhere near ready to slow down on its progress. With the engine and transmission well taken care of, the next phase of the build was one that would not present any curveballs for Richard. Being an expert body shop technician, he was well equipped to take on the upcoming body and paintwork in what would be the easiest stretch of the seven-year ordeal. Aside from the routine metal work to get the truck ready for paint, Richard utilized the availability of SelfMade Fab’s shaved and bead-rolled firewall panels and front and rear wheel tubs. A factory C60 grill was then chrome plated before installation, and a wood bed floor was laid down and finished off with a center access panel to better reach the vital components below deck.
Next, Richard began the process of narrowing down paint colors, which promptly halted once he landed on PPG’s Dodge Hemi Orange Pearl for the body and Wimbledon White for the roof. With the inclusion of more freshly chromed parts and pieces, the exterior of the ’66 was looking as cool and timeless as it gets.
“Inside the cab, a combination of pewter material was utilized when reupholstering the factory bench seat and the factory Deluxe model steering wheel.”
Inside the cab, a combination of pewter material was utilized when reupholstering the factory bench seat and the factory Deluxe model steering wheel. A matching fawn-colored paint was then selected to cover the dash and door panels. The interior color palette is independent of that used on the truck’s outward landscape, which makes for a welcomed change of environment while settling in for a long drive. The toned-down in-cab appearance matches the classic demeanor of the truck’s exterior with its smooth, subtle styling—a feat that wasn’t so simple to pull off.
Once the dust settled on the project, Richard Jr. finally had the truck he had wanted years ago—only in better condition than he could’ve ever imagined. While time and money always present hurdles with a project this extensive, he took it all in stride. Richard had an exact vision in mind, so to get there, he took the extra time to do things right, and he saved up the extra money required to purchase the specific parts he just had to have.
“The one thing the truck constantly gets compliments on is its originality with that little bit of custom flare…”
“The only advice I can give to anyone is that do not ever give up on your vision,” Richards offers. “If you have a certain look that you want to maintain throughout your project, go that extra mile and do what you have to do. The one thing the truck constantly gets compliments on is its originality with that little bit of custom flare, which was actually more difficult than I would’ve guessed. I am hoping this truck will give my son and me the opportunity to create wonderful memories like how I was able to make with my dad.”
RICHARD HOPKINS
1966 Chevy C10
Burlington, NC
Relaxed Atmosphere
Shop: Richard Hopkins and his father, Big Rich
1957 Chevy V-8 283c.i.
OEM connecting rods
TRW .030 over pistons
Sealed Power rings
Drilled and tapped crankshaft to accept newer balancer bolt
Comp Cams Nostalgic Plus flat cam, valve springs, locks and keepers
258/265 lift and 211/218 duration
Power Pack heads milled .020 and hardened valve seats
ARP screw in rocker studs
Edelbrock Performer RPM intake manifold and 1403 carburetor
Hooker F-Body mid-length headers, 1.5-inch primaries to 2.5-inch collector, Jet Hot coating
Aluminized Deeds Engineering DIY exhaust kit welded together with H-pipe
MSD HEI ignition
Concept 1 pulley setup in black anodized
Customized factory C60 air cleaner
Offenhauser staggered bolt valve covers
Taylor plug wires
1969 TH350 transmission
Energy Suspension trans bushing
Polished finned aluminum pan
B&M shift kit
Boss Hoss torque converter
Milled direct clutch piston to receive extra friction clutch and steel
Porterbuilt front to rear crossmembers, Dropmember 3 and rear setup
Powdercoated complete frame
Trans crossmember modified to keep exhaust above frame bottom
Narrowed control arms
Firestone convoluted front ‘bags, rear sleeve ‘bags
Ridetech HQ shocks
Unisteer power rack and pinion
Porterbuilt 1.5-inch front sway bar
Dual Viair compressors
Accuair e-Level air management
Inland Empire 2-piece driveshaft w/ slip yoke and billet carrier bearing
Factory 1966 Chevy 12-bolt rearend
CPP 6-to-5-lug rear axle swap
Strange Engineering LPW diff support cover
Two Optima batteries
22×9 Centerline Smoothie wheels
265/35R22 Falken Ziex S/TZ tires
CPP front modular disc brakes, factory rear drums powdercoated
Wilwood tandem master cylinder w/ proportioning valve
Factory C60 grille chrome plated
Sylvania Silverstar sealed beam headlights
Raised and bead rolled front and rear wheel tubs by Selfmade Fab
PPG base clean DBC Hemi orange pearl w/ Wimbledon white roof
Shop: Steve Kurzman, former owner of The Custom Stitching Company, Charlotte, NC
OEM seat frame covered in vintage fawn leather upholstery with tinsel piping
Matching sun visors and leather covered fuel tank panels
Complete painted interior and eggshell flattened and cleared
1961 Chevy truck Deluxe arm rests
OEM gauges reconditioned with tach
1966 custom model steering wheel
Flaming River street rod tilt column
Vintage Air A/C and heat
Removable trans tunnel buck to access transmission
